Brand
|
ADVANCE TOGETHER |
|
Type
|
DC/AC Inverters
|
|
Output Type
|
Single/Triple
|
|
Output Voltage
|
0-400V
|
|
Output Frequency
|
50/60HZ
|
|
Certificate
|
other
|
|
Warranty
|
18Month
|
|
Display
|
Digital
|
|
Features
|
Vector control
|
|
application
|
industry
|
|
AC Drive Model |
Power Capacity (kVA)
|
Input Current (A)
|
Output Current (A)
|
Adaptabl Motor (kW)
|
||||
|
Three-phase 380 V, 50/60 Hz
|
||||||||
|
3300-0R7G-4
|
1.5
|
3.4
|
2.1
|
0.75
|
||||
|
3300-1R5G-4
|
3
|
5
|
3.8
|
1. 5
|
||||
|
3300-2R2G-4
|
4
|
5.8
|
5.1
|
2.2
|
||||
|
3300-004G-4
|
5.9
|
10.5
|
9
|
4
|
||||
|
3300-5R5G-4
|
8.9
|
14.6
|
13
|
5.5
|
||||
|
3300-7R5G-4
|
11
|
20.5
|
17
|
7.5
|
||||
|
3300-011G-4
|
17
|
26
|
25
|
11
|
||||
|
3300-015G-4
|
21
|
35
|
32
|
15
|
||||
|
3300-018G-4
|
24
|
38.5
|
37
|
18.5
|
||||
|
3300-022G-4
|
30
|
46.5
|
45
|
22
|
||||
|
3300-030G-4
|
40
|
62
|
60
|
30
|
||||
|
3300-037G-4
|
57
|
76
|
75
|
37
|
||||
|
3300-045G-4
|
69
|
92
|
91
|
45
|
||||
|
3300-055G-4
|
85
|
113
|
112
|
55
|
||||
|
3300-075G-4
|
114
|
157
|
150
|
75
|
||||
|
3300-090G-4
|
134
|
180
|
176
|
90
|
||||
|
Item
|
Specifications
|
||||
|
Standard functions |
Maximum frequency
|
• Vector control: 0–300 Hz
• V/F control: 0–320 Hz |
|||
|
Carrier frequency |
0.5–16 kHz
The carrier frequency is automatically adjusted based on the load features. |
||||
|
Input frequency resolution
|
Digital setting: 0.01 Hz
Analog setting: maximum frequency x 0.025% |
||||
|
Control mode |
• Sensorless flux vector control (SFVC)
• Closed-loop vector control (CLVC) • Voltage/Frequency (V/F) control |
||||
|
Startup torque |
• G type: 0.5 Hz/150% (SFVC); 0 Hz/180% (CLVC)
• P type: 0.5 Hz/100% |
||||
|
Speed range
|
1:100 (SFVC)
|
1:1000 (CLVC)
|
|||
|
Speed stability accuracy
|
• ± 0.5% (SFVC)
• ± 0.02% (CLVC) |
||||
|
Torque control accuracy
|
± 5% (CLVC)
|
||||
