VFD Model | Input Voltage | Rated Output Power(KW) | Rated Input Current(A) | Rated Output Current(A) | Applicable Motor(KW) |
GD200-0R4G-S2-PV | Single Phase 220V | 0.4 | 6.5 | 2.5 | 0.4 |
GD200-0R7G-S2-PV | 0.75 | 9.3 | 4.2 | 0.75 | |
GD200-1R5G-S2-PV | 1.5 | 15.7 | 7.5 | 1.5 | |
GD200-2R2G-S2-PV | 2.2 | 24 | 10 | 2.2 | |
GD200-0R7G-4-PV | Three Phase 380V | 0.75 | 3.4 | 2.5 | 0.75 |
GD200-1R5G-4-PV | 1.5 | 5 | 4.2 | 1.5 | |
GD200-2R2G-4-PV | 2.2 | 5.8 | 5.5 | 2.2 | |
GD200-004G-4-PV | 4 | 13.5 | 9.5 | 4 | |
GD200-5R5G-4-PV | 5.5 | 19.5 | 14 | 5.5 | |
GD200-7R5G-4-PV | 7.5 | 25 | 18.5 | 7.5 | |
GD200-011G-4-PV | 11 | 32 | 25 | 11 | |
GD200-015G-4-PV | 15 | 40 | 32 | 15 | |
GD200-018G-4-PV | 18.5 | 47 | 38 | 18.5 | |
GD200-022G-4-PV | 22 | 51 | 45 | 22 | |
GD200-030G-4-PV | 30 | 70 | 60 | 30 | |
GD200-037G-4-PV | 37 | 80 | 75 | 37 | |
GD200-045G-4-PV | 45 | 94 | 92 | 45 | |
GD200-055G-4-PV | 55 | 128 | 115 | 55 | |
GD200-075G-4-PV | 75 | 160 | 150 | 75 | |
GD200-090G-4-PV | 90 | 190 | 180 | 90 | |
GD200-110G-4-PV | 110 | 225 | 215 | 110 |
Function | Specification | ||
Input | Input Voltage(V) | DC 900V(-15%) | |
Input Frequency(Hz) | 47~63Hz | ||
Output | Output Voltage(V) | 0~Input Voltage | |
Output Frequency(Hz) | 0~400Hz | ||
Output Power(KW) | 4~110KW | ||
Control Mode | SVPWM, Sensorless Vector Control | ||
Motor Type | Asynchronous Motor/PMSM Motor | ||
Speed Ratio | 1:100(SVC) | ||
Technical Control Feature | Speed Control Accuracy | ±0.2%(Sensorless Vector Control) | |
